The Gazelle 60cc Cadet UK engine was specifically designed to meet the needs of the MSUK.
The Gazelle adopts an easy and effective pull start system and a Tillotson carburetor. The Gazelle 60cc is the power unit of the incredibly successful Cadet class, paving the way for the youngest competitors to a future Motorsport career.
Iame Gazelle - UK Cadet - Specs
Model | Cadet 60cc UK |
Category | Cadet MSA |
Homologation | National |
Displacement | 59.42cc (60cc Max) |
Bore | 41.80 (42.00 Max) |
Stroke | 43.33mm |
Starter | Pull Start |
Transmission | 3 Masses Dry Clutch |
Cooling System | Air Cooled |
Number Of Transfers | 2 |
Fuel Mixture | 3% |
Admission | Piston Port |
Spark Plug | NGK BR 10 EG |
Carburettor | Tillotson HL394A (16mm) |
